A285 Pressure Vessel Carbon Steel Coil

Name: A285 Pressure Vessel Carbon Steel Coil
SKU: 0

A285 pressure vessel steel coil is made of a common carbon steel used for fusion welding of pressure vessel equipment such as boilers, storage tanks, heat exchangers, etc..

Phone ：+86 18888888888

WhatsApp : +86 18888888888

Email : admin@admin.com

Contact Us

Product Description

A285 pressure vessel steel coil consists of 3 grades: Grade A, Grade B, and Grade C. A285 coils have good welding performance and can meet the fusion welding requirements of pressure vessel equipment. ASTM A285 Boiler vessel steel coils are widely applied in petroleum, chemical, boiler and other industries, and is used in the production of reactors, heat exchangers, separators, spherical tanks, gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas cylinder plants, hydropower stations High-pressure water pipes, turbine casings and other equipment and components.

Product Parameters

Product Name	A285 Pressure Vessel Carbon Steel Coil
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	45mm-2200mm
Length	Custom Size
Thickness	Hot Rolling: 2.75mm-100mm Cold Rolling: 0.2mm-3mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

A285	C	Mn	P	S
Class A	0.17	0.98	0.025	0.025
Class B	0.22	0.98	0.025	0.025
Class C	0.28	0.98	0.025	0.025

Mechanical Properties

A285	Thickness mm	Yield Mpa	Tensile Strength Mpa	Elongation (%)
Class A	6-50	165	310-450	30 %
Class A	50-200	165	310-450	27 %
Class B	6-50	185	345-485	28 %
Class B	50-200	185	345-485	25 %
Class C	6-50	205	380-515	27 %
Class C	50-200	205	380-515	23 %

Physical Performance

Physical Performance	Metric	Imperial
Density	7.80 g/cc	0.282 lb/in³

Scope of Application

ASTM A285 boiler vessel plate is a medium and low strength carbon steel plate for pressure vessel. It is widely used in the manufacture of reactor, heat exchanger, separator, spherical tank, oil and gas tank, nuclear reactor pressure shell, high pressure water pipe, turbine shell and other equipment.

Equivalent Material

National Standard	American Standard	European Standard	German Standard	Japan Standard	France	United Kingdom	Italy	Australia	ISO	India
20	A285	P235GH (1.0345)	1.0345	SB410	A37AP	141-360	Fe 360-1KG	St35KW	P3	Grade 1
20	A285 Gr.C	P235GH (1.0345)	ASt35	SGV410	A37CP	161 Gr.360	Fe 360-1KW	St35KW	P3	Grade 1

Product Display

Factory Display

FAQ

1.What kind of customer service do you provide?

We provide comprehensive customer service, including basic design, procurement of supporting facilities, and options for dispatching installation guides.

2.What are the customer evaluations of your company?

We are proud to consistently receive five-star reviews from our customers, which demonstrates our commitment to quality and service.

3.What is your quality inspection process like?

Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished products, every stage is carefully inspected to ensure excellent quality.

4.Do you accept container loading inspection?

Welcome to dispatch inspectors, not only for container loading, but also at any time during production.

5.What is the delivery time?

The delivery time depends on the quantity of orders. Usually, the delivery time to the nearest port in China is 15-30 days after receiving the deposit.

6. How to obtain a project quotation?

You can contact us 24 * 7 via email, phone, WhatsApp, WeChat, etc. You will receive a reply within 4 hours.
